100 Watt 12 Volt 110W 120W Monocrystalline Semi-Flexible Bendable Mono off-Grid Charger Flexible Solar Panel for Marine RV Cabin Van Car Uneven Roof Surfaces
Package size per unit product 10.00cm * 10.00cm * 10.00cm Gross weight per unit product 1.000kg High Efficiency Bendable
Basic Info
Condition | New |
Certification | CE |
Material | Monocrystalline Silicon |
Transport Package | Master Carton |
Trademark | OEM |
Origin | China |
HS Code | 8504401400 |
Production Capacity | 10000000 PCS/Month |
Packaging & Delivery
Package size per unit product 10.00cm * 10.00cm * 10.00cm Gross weight per unit product 1.000kgProduct Description
High Efficiency Bendable PV modulesThe high efficiency bendable PV modules(Flexible modules) adopt the world's highest conversion efficiency back~contact solar cells, the efficiency of the module is 30% higher than that of the conventional ones. As these modules are bendable, Hongjoy Technology Solar high efficiency bendable PV modules are widely applied to electric golf cars, patrol cars, tourism cars, yachts, roof power generation systems, backpacks, tents etc.Product Specification100 Watt Monocrystalline Bendable Photovoltaic ModuleMade with high efficiency back-contact solar cellsElectrical CharacteristicsMax Power | Pmax | 100W |
Max Power Voltage | Vmp | 17.8V |
Open Circuit Voltage | Voc | 21.6V |
Maximum System Voltage | Voc | 600V |
Temperature Co-efficients | Power | -0.38%/ºC |
Voltage | -60.8mV/ºC | |
Current | 2.2mA/ºC | |
Cell Efficiency | 21% | |
Number of Cells in Series | 32 | |
Max Power tolerance | ±5% | |
Mechanical Characteristics Weight | KGS | 2.0KG |
Dimension | mm | 1060*540*3 |
Here are more options for your selection:
Pm | Voc | Isc | Vmp | Imp | C-eff | N.W. | Dimension(mm) |
18W | 23.7V | 0.98A | 19.8V | 0.91A | 20.30% | 0.50kg | 434*277*3 |
30W | 21.2V | 1.83A | 17.6V | 1.70A | 19.50% | 0.75kg | 535*378*3 |
50W | 21.2V | 3.05A | 17.6V | 2.84A | 21.50% | 1.20kg | 545*535*3 |
60W | 42.3V | 1.86A | 35.2V | 1.71A | 19.20% | 1.46kg | 725*535*3 |
80W | 18.5V | 5.58A | 15.4V | 5.19A | 19.60% | 1.80kg | 922*540*3 |
90W | 21.4V | 5.52A | 17.6V | 5.12A | 19.00% | 2.00kg | 1050*540*3 |
95W | 21.4V | 5.77A | 17.7V | 5.37A | 20.00% | 2.00kg | 1050*535*3 |
100W | 21.6V | 5.97A | 17.8V | 5.62A | 21.00% | 2.00kg | 1050*540*3 |
110W | 23.7V | 5.91A | 19.8V | 5.56A | 20.60% | 2.22kg | 1175*540*3 |
120W | 26.4V | 5.87A | 22.0V | 5.45A | 20.50% | 2.45kg | 1305*540*3 |
130W | 29.4V | 5.76A | 24.4V | 5.32A | 20.00% | 2.67kg | 1435*540*3 |
135W | 29.6V | 5.90A | 24.6V | 5.49A | 20.70% | 2.67kg | 1435*540*3 |
More Specifications, customized are Supported and Welcomed.
Welcome for more information.
